Lift and slide doors veka

LIFT-AND-SLIDE DOOR VEKAMOTION 82

The new VEKAMOTION 82 system is the result of VEKA's advanced solutions that improve product quality. This is not a typical lift and slide system, although the construction -  leaves and  threshold- is similar to the HS system. In VEKAMOTION 82 fitting, the leaf is detached from the frame on opening and slides only then.

LARGE GLAZINGS IN THE HOUSE

Thanks to its unique design, VEKAMOTION 82 makes it possible to build large doors using narrow profiles. As a result, glass walls allow for perfect lighting of the interior in an impressive way and also blend the interior of the house into its ambience.

VEKAMOTION 82 allows the design of 2-leaf structures with dimensions of 6.5 m wide and 2.7 m high with white profiles and 5 m wide and 2.5 m high with coloured profiles. 3 and 4 leaf constructions can be 6.5 m wide regardless of the profile colour.



Diagram of possible implementation

LARGE GLAZING AND ENERGY EFFICIENCY

VEKAMOTION 82 fitting ensures better adhesion of the leaf and the construction achieves better thermal insulation parameters than the standard HS system. This new system for creating terrace doors also offers the possibility of installing warm triple or quadruple glazing packages up to 54 mm thick.

In addition, thanks to the innovative VEKAMOTION 82 seals, it guarantees water resistance in the highest class 9A and wind resistance in class 4.

WIDE RANGE OF COLOURS

VEKAMOTION 82 provides a wide choice of design and profile colours. You can choose from RAL colours, woodgrain and the option to order aluminium clad.

CUSTOMISED PVC SLIDING DOORS

At Aikon Distribution, we customise our products to meet our customers' needs. Therefore, we give you the opportunity to specify your preferences regarding dimensions, colours, leaf layout, number of sections and additional profiles of the selected goods. We also fulfill non-standard and sophisticated orders. Most importantly, we give our customers the option of customisation already with the purchase of one product.

Installation depth  194 mm
Number of chambers  7-chamber door frame and 4-chamber leaf frame profiles
Heat transfer coefficient  Uf = 1,4 W/m2*K
Profile class  A
Weather stripping  EPDM
Available pane fixations thicknesses  24-54 mm
Standard glazing  4/16/4
Standard handle  door handle internally, cup pull handle externally
Steel thickness  2 mm
Dyed profile core for 2s colors white
Warranty 2 years
Certificates Hygienic Certificate+IFT certification for mechanical properties
Order processing time  from 5-9 weeks

Additional parameters

Colors
Additional profiles and accessories
Ornamental window panes
Windows with roller shutters

Download technical drawings
