SLIDING WINDOWS ALUPLAST MONORAIL
PRODUCT DISCONTINUED.
Get in touch with our sales representative to ask for an alternative for this product.
Sliding sash window system is a modern and functional solution available in the Aluplast system. Monorail system allows to create large glazed surfaces in residential and commercial buildings
Sliding window in the kitchen
Single rail is used for light Aluplast Monorail system where window sash containing single glass pane is supported with brush seals. Monorail Technology is especially recommended for indoor use. As oppose to traditional side-hung doors, sliding sash opens along the fixed element allowing the system to be used in less spacious room.
uPVC made-to-measure sliding doors
Our clients can specify dimensions, colours number of sashes and additional profiles. Variety of technical solutions enable production of large dimension windows undertaking the most sophisticated custom orders even when ordering just one door. In our offer you will also find HST sliding doors.
Images are for reference purposes only.
Installation depth
60mm
Number of chambers
4 chambers
Heat transfer coefficient
Uf = 2,1 W/m2*K
Profile class
B
Weather stripping
"Brush" type, black
Available pane fixations thicknesses
3-9 mm
Standard glazing
Single 4mm pane
Number of rails
1
Steel thickness
-
Dyed profile core for 2s colors
Yes: brown or brown core under the veneer
Warranty
2 years
Certificates
CE,CEKAL (concerning panes)
Order processing time
from 3 weeks
Additional parameters
Download technical drawings
Download our catalogue
PRODUCT DISCONTINUED.
Get in touch with our sales representative to ask for an alternative for this product.
Sliding sash window system is a modern and functional solution available in the Aluplast system. Monorail system allows to create large glazed surfaces in residential and commercial buildings
Sliding window in the kitchen
Single rail is used for light Aluplast Monorail system where window sash containing single glass pane is supported with brush seals. Monorail Technology is especially recommended for indoor use. As oppose to traditional side-hung doors, sliding sash opens along the fixed element allowing the system to be used in less spacious room.
uPVC made-to-measure sliding doors
Our clients can specify dimensions, colours number of sashes and additional profiles. Variety of technical solutions enable production of large dimension windows undertaking the most sophisticated custom orders even when ordering just one door. In our offer you will also find HST sliding doors.
Images are for reference purposes only.
| Installation depth | 60mm |
| Number of chambers | 4 chambers |
| Heat transfer coefficient | Uf = 2,1 W/m2*K |
| Profile class | B |
| Weather stripping | "Brush" type, black |
| Available pane fixations thicknesses | 3-9 mm |
| Standard glazing | Single 4mm pane |
| Number of rails | 1 |
| Steel thickness | - |
| Dyed profile core for 2s colors | Yes: brown or brown core under the veneer |
| Warranty | 2 years |
| Certificates | CE,CEKAL (concerning panes) |
| Order processing time | from 3 weeks |
Additional parameters
Download technical drawings
Download our catalogue
